Forged Machienery Eye Bolt S-279 UNC
- Category:Eye Bolts & Nuts
- Material:Stainless steel
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China Forged Machienery Eye Bolt S-279 UNC:
| SIZE |
WORKING LOADLIMIT (lbs.) |
WEIGHT PRR 100(lbs.) |
DIMENSIONS (in.) | |||||||
|
A THREAD |
B | C | D | E | F | G | H | |||
| 1/4 x 1 | 650 | 5.00 | 1/4-20 | 1.02 | 1.13 | 0.75 | 2.29 | 0.19 | 0.53 | 0.77 |
| 5/16 x 1-1/8 | 1200 | 9.00 | 5/16-18 | 1.15 | 1.38 | 0.88 | 2.74 | 0.25 | 0.59 | 0.95 |
| 3/8 x 1-1/4 | 1550 | 15.00 | 3/8-16 | 1.27 | 1.62 | 1.00 | 3.07 | 0.31 | 0.69 | 1.05 |
| 1/2 x 1-1/2 | 2600 | 28.00 | 1/2-13 | 1.53 | 1.95 | 1.19 | 3.70 | 0.38 | 0.91 | 1.27 |
| 5/8 x 1 -3/4 | 5200 | 55.00 | 5/8-11 | 1.79 | 2.38 | 1.38 | 4.45 | 0.50 | 1.13 | 1.53 |
| 3/4 x 2 | 7200 | 96.00 | 3/4-10 | 2.05 | 2.76 | 1.50 | 5.07 | 0.63 | 1.38 | 1.71 |
| 7/8 x 2-1/4 | 10600 | 154.00 | 7/8-9 | 2.31 | 3.25 | 1.75 | 5.87 | 0.75 | 1.56 | 2.00 |
| 1 x 2-1/2 | 13300 | 238.00 | 1-8 | 2.57 | 3.76 | 2.00 | 6.66 | 0.88 | 1.81 | 2.30 |
| 1-1/8 x 2-3/4 | 15000 | 320.00 | 1-1/8-7 | 2.75 | 4.19 | 2.25 | 7.20 | 0.97 | 2.06 | 2.35 |
| 1-1/4 x 3 | 21000 | 399.00 | 1-1/4-7 | 3.09 | 4.50 | 2.50 | 7.95 | 1.00 | 2.28 | 2.73 |
| 1-1/2 x 3-1/2 | 24000 | 720.00 | 1-1/2-6 | 3.60 | 5.50 | 3.00 | 9.49 | 1.25 | 2.75 | 3.28 |
| 1 -3/4 x 3-3/4 | 34000 | 1040.00 | 1-3/4-5 | 3.75 | 6.26 | 3.50 | 10.48 | 1.38 | 3.00 | 3.60 |
| 2 x 4 | 42000 | 1880.00 | 2-4-1/2 | 4.00 | 7.62 | 4.00 | 12.31 | 1.81 | 3.38 | 4.50 |
| 2-1/2 x 5 | 65000 | 3250.00 | 2 -1/2-4 | 5.00 | 8.76 | 4.50 | 14.88 | 2.12 | 4.25 | 5.50 |
