QJ1824-30A and QJ1824-40A Marine DC regulated power supply

Request a Quote Not what you need, please send your RFQs via Email.
Download this page

Details

QJ1824-30A and QJ1824-40A Marine DC regulated power supply

Model Input Output Output Ripple Dimensions Weight
voltage voltage Noise (WxHxD) (Kg)
QJ1824-20A AC110/220V DC24V 20A ≤25mV 235x150x420mm 14.8kg
DC24V
QJ1824-30A AC110/220V DC24V 30A ≤25mV 235x150x420mm 14.8kg
DC24V
QJ1824-40A AC110/220V DC24V 40A ≤25mV 235x150x420mm 14.8kg
DC24V
QJ1820 AC110/220V DC12V 20A ≤25mV 235x150x420mm 14.8kg
DC12V
QJ1830 AC110/220V DC12V 30A ≤25mV 235x150x420mm 14.8kg
DC12V
QJ1840 AC110/220V DC12V 40A ≤25mV 235x150x420mm 14.8kg
DC12V
