65CWZ-8 Marine horizontal self-priming centrifugal pump

Request a Quote Not what you need, please send your RFQs via Email.

Details

Product overview

CWZ series marine horizontal self-priming centrifugal pump is suitable for marine cooling pump, sanitary pump, fire pump, bilge ballast pump, etc.

Model description

Model Flow Rate
m3/h
Height
m
NPSH
m
Speed
r/min
Motor
kW
32CWZ-3 8 42 4 2950 4
32CWZ-4 8 30 4 2.2
32CWZ-5 8 21 4 1.5
40CWZ-4 12 42 4 4
40CWZ-5 12 30 4 3
40CWZ-6 12 21 4 2.2
50CWZ-5 21 42 4 5.5
50CWZ-6 21 30 4 4
50CWZ-8 21 21 4 3
50CWZ-11 21 15 4 2.2
65CWZ-5 30 60 5 15
65CWZ-6 36 42 5 11
65CWZ-8 36 30 4 5.5
65CWZ-11 36 21 4 4
80CWZ-5.5 60 75 5 30
80CWZ-6 60 50 5 22
80CWZ-11 60 30 4 11
80CWZ-14 60 21 4 7.5
100CWZ-6 100 85 5 55
100CWZ-8 100 60 5 37
100CWZ-11 100 40 5 22
100CWZ-14 100 30 5 15
100CWZ-18 100 21 5 11
150CWZ-16 180 30 4.5 37
150CWZ-22 200 25 4.5 37
200CWZ-15 300 25 6.5 1450 37
250CWZ-20 550 22 5 75
32CWZ-5(Z) 8 21 2950 1.5 4
40CWZ-4A(Z) 12.5 32 2950 3 4
40CWZ-5(Z) 12 30 2950 3 4
40CWZ-6(Z) 12 20 2950 2.2 4
50CWZ-4(Z) 13.5 22.5 2900 2.2 5
50CWZ-5(Z) 21 42 2950 5.5 5
50CWZ-6(Z) 25.5 18 2900 3 4
65CWZ-6(Z) 36 42 2950 11 5
65CWZ-8(Z) 36 30 2950 5.5 4
65CWZ-11(Z) 36 21 2950 4 4
80CWZ-6(Z) 60 60 2950 22 5
80CWZ-6(Z)A 52 56 2950 18.5 5
80CWZ-8(Z) 60 42 2950 15 5
80CWZ-11(Z) 50 30 2950 11 4
80CWZ-14(Z) 60 21 2950 7.5 4
