A60 Class Floating Deck

No.	Item name		Index	Standard
1	Fireproof Deck Covering	Initial setting time	≥1h	Q/HCF 1-2004
2		Final setting time	≤12h
3		Modulus of rapture	≥4MPa
4		Compressive strength	≥20MPa
5		Density	≤1600kg/m3
6		Water absorption	≤10%
7		Oil absorption	≤5%
8		Heat conductivity	≤1.2W/m.k
9		Non-combustibility	In accordance with IMO.FTPC Part 1/IMO.A 799(19)
10	Deck Structure	Fire Rating	A-60
11		Weight per square meter	≤50 kg/m2/50mm

Characteristic: Vibration resistance, impact resistance, sound absorption, elastic, fire rating is A-60 class

Applied: Covering for A-60 class decks and other approx. A-60 class structures.

Consume amount: 40 kg/m2 (HH-3 face layer)

Packing: Dry material (A component): 30kg/pack, supply steel meshes, PE waterproof films and ceramic boards in package counting in areas

Storage: Cool and dry place, moisture-proof, the quality guarantee period is 6 months

Certificate: ABS、BV、CCS、DNV、EC、GL 、KR、LR、NK
