ANSI Sch40 Butt Welding Eccentric Reducer

Nominal Pipe Size(NPS)

Outside
Diameter
at Bevel(O/D)

End
to
End

Nominal Pipe Size(NPS)

Run

Outlet

H

¾'' x ½''
¾'' x 3/8''

26.7
26.7

21.3
17.3

38
38

12'' x 10'' 12'' x 8'' 12'' x 6'' 12'' x 5''

1'' x ¾''
1'' x ½''

33.4
33.4

26.7
21.3

51
51

1.1/4'' x 1''
1.1/4'' x ¾''
1.1/4'' x ½''

42.2
42.2
42.2

33.4
26.7
21.3

51
51
51

14'' x 12'' 14'' x 10'' 14'' x 8'' 14'' x 6''

1.1/2'' x 1.1/4''
1.1/2'' x 1''
1.1/2'' x ¾''
1.1/2'' x ½''

48.3
48.3
48.3
46.3

42.2
33.4
26.7
21.3

64
64
64
64

16'' x 14'' 16'' x 12'' 16'' x 10'' 16'' x 8''

2'' x 1.1/2''
2'' x 1.1/4''
2'' x 1''
2'' x ¾''

60.3
60.3
60.3
60.3

48.3
42.2
33.4
26.7

76
76
76
76

18'' x 16'' 18'' x 14'' 18'' x 12'' 18'' x 10''

2.1/2'' x 2''
2.1/2'' x 1.1/2''
2.1/2'' x 1.1/4''
2.1/2 x 1''

73.0
73.0
73.0
73.0

60.3
48.3
42.2
33.4

89
89
89
89

20'' x 18'' 20'' x 16'' 20'' x 14'' 20'' x 12''

3'' x 2.1/2''
3'' x 2''
3'' x 1.1/2''
3'' x 1.1/4''

88.9
88.9
88.9
88.9

73.0
60.3
48.3
42.2

89
89
89
89

22'' x 20'' 22'' x 18'' 22'' x 16'' 22'' x 14'
