CLV Marine Vertical Centrifugal Pump

Request a Quote Not what you need, please send your RFQs via Email.

Details

Description:

Technical data:

Model Capacity
(m3/h)
Head
(m)
Speed
(r/min)
NPSH
(m)
Shaft Power
kw
Efficiency
%
Power
(kw)
CLV65-200A 27 14.5 1450 2.5 1.8 59.2 2.2
CLV65-280A 30 21 1450 2.5 3.1 55.3 4
CLV65-300A 30 28 1450 2.5 4.4 52 5.5
CLV65-350A 25 41 1450 2.5 6.1 45.8 7.5
CLV80-200A 48 14.5 1450 2.5 2.8 67.7 4
CLV80-220B1 45 48 2900 4.0 9.8 60 11
CLV80-220A 45 62 2900 4.0 12 63.3 15
CLV80-280A 54 21.5 1450 3.0 4.5 70.3 5.5
CLV80-300A 46 28 1450 2.8 5.8 60.5 7.5
CLV80-350B 40 35 1450 2.5 6.9 55.3 11
CLV80-350A 54 41 1450 3.0 10.5 57.4 15
CLV80-350B2 42 41 1450 2.5 8.4 55.8 11
CLV100-200A 83 14.5 1450 3.2 4.6 71.3 5.5
CLV100-220B 87 55 2900 4.5 18.5 70.4 22
CLV100-220A 95 68.5 2900 4.5 24.2 73.2 30
CLV100-280A 83 21 1450 3.0 6.4 74.2 7.5
CLV100-300A 83 28 1450 2.8 9.1 69.5 11
CLV100-350A 83 41 1450 3.2 14.2 65.3 18.5
CLV125-200A 116 14 1450 3.5 5.9 75 7.5
CLV125-220B 128 55 2900 5.0 26.7 71.8 37
CLV125-220A 149 68.5 2900 5.5 36.9 75.3 45
CLV125-270A 140 86 2900 5.0 44.7 73.4 55
CLV125-280A 125 21 1450 3.5 9.6 74.5 11
CLV125-350B 116 34 1450 3.5 15.9 67.6 22
CLV125-350A 125 41 1450 3.5 19.8 70.5 30
CLV150-350B2 190 35 1450 3.5 25.6 70.7 30
CLV200-200A 332 13.7 1450 4.0 15.9 77.9 18.5
CLV200-280B 290 17 1450 4.5 17.3 77.6 22
CLV200-280A 330 20.5 1450 4.5 23.4 78.7 30
CLV200-280B2 250 20.5 1450 4.0 17.9 78.0 22
CLV200-300A 325 27.5 1450 4.5 30.3 80.3 37
