CLZ Series vertical centrifugal self-priming marine pumps
- Category:Centrifugal Pump
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China CLZ Series vertical centrifugal self-priming marine pumps:
CLZ series vertical centrifugal self-priming marine pumps are of small volumn, low weight and high function of self-priming.The type of pump is suitable for ballast, fire control, cooling and so on the bilge in all kinds of ships and warships .But the mediums temperature should be lower than 80℃
| Type | Capacity | Head | NPSHr | Efficiency |
| (m3/h) | (m) | (m) | (%) | |
| 40CLZ-2 | 5 | 60 | 3.5 | 19 |
| 40CLZ-2A | 4 | 54 | 3.5 | 19 |
| 40CLZ-2B | 4 | 38 | 3.5 | 19 |
| 50CLZ-4.5 | 12.5 | 32 | 4 | 41 |
| 50CLZ-4.5A | 11.2 | 26 | 4 | 41 |
| 50CLZ-4.5B | 10 | 28 | 4 | 41 |
| 50CLZ-4.5C | 10 | 20.5 | 4.5 | 42 |
| 50CLZ-6 | 20 | 32 | 4 | 49 |
| 50CLZ-6A | 17 | 28 | 4 | 49 |
| 50CLZ-9 | 27 | 14.5 | 4 | 57 |
| 50CLZ-9A | 21 | 12 | 4 | 55 |
| 50CLZ-7 | 12.5 | 20 | 4 | 51 |
| 50CLZ-7A | 10 | 17 | 4 | 51 |
| 50CLZ-7B | 10 | 14 | 4 | 50 |
| 50CLZ-3 | 12.5 | 50 | 4 | 35 |
| 50CLZ-3A | 10 | 45 | 4 | 35 |
| 50CLZ-3B | 10 | 32 | 4 | 35 |
| 50CLZ-4 | 20 | 50 | 4 | 42 |
| 50CLZ-4A | 17 | 46 | 4 | 42 |
| 50CLZ-4B | 17 | 36 | 4 | 42 |
| 65CLZ-9 | 25 | 20 | 4 | 61 |
| Also have bigger pumps, pls contact us for more information. | ||||
