ESD3000IR Infrared Gas Detector
- Category:Monitoring And Alarming Device
- Fob Price:Get Latest Price Now
- Place of Origin:China
Details
Introduction
●Infrared Gas Detector in industrial application
●Ex-proof certificate Exd ⅡC T6 Gb
●Dust Ex-proof certificate Ex tD A21 IP66 T80℃
●Site LCD display
●HART communication
●Changeable sensor design
●Optional in audial and visual alarm with relay output
Specifications
2.17kg (aluminum alloy)/4.1kg (stainless steel)
GB 15322.1-2003, GB 3836.1-2010,
GB 3836.2-2010, GB 3836.4-2010,
GB 12476.1-2013, GB 12476.4-2010 ,
GB 12476.5-2013, JJF 1368-2012
3-wire 4~20mA+HART+relay (1A@24VDC)+audial & visual alarm (96dB ＠0.1m)
No.
Items
ESD3000IR
No.
Items
ESD3000IR
1
Display
LCD
12
Screw connection
M20X1.5, 1/2NPT internal thread (select G3/4 or G1/2 or 3/4NPT)
2
Detected gases
combustible gas/CO2
13
Weight
3
Detecting principle
Infrared Spectroscopy
4
Measurement Range
0～100%LEL (combustible gas)/0～5%v/v (CO2)
14
Explosion proof certificate
Exd ⅡC T6 Gb/Ex t D A21 IP66 T80℃
5
Accuracy
±3%LEL (combustible gas)/±3%FS (CO2)
15
Fire safety certificate
CCCF
6
Repeatability
±2%
16
China metrology certification
CMC
7
Response time
T90＜20S
17
Standard
8
Power supply
24VDC（normal work voltage scope：10～30VDC)
9
Power consumption
＜2.5W
18
IP rating
IP66
10
Output signal
19
Temperature scope
-40℃～70℃
11
Main material
ADC12 aluminum alloy/316 stainless steel
20
Humidity scope
10～95%RH(non-condensing）
21
Atmospheric pressure
86～106KPa
Flammable Gases Detectable by ESD3000IR
| No. | Description | Formula | No. | Description | Formula |
| K001 | Methane | CH4 | K022 | Pentane | C5H12 |
| K002 | Methylbenzene | C6H5CH3 | K023 | Hexane | CH3(CH2)4CH3 |
| K003 | Methanol | CH3OH | K024 | Heptane | C7H16 |
| K004 | Methyl formate | HCOOCH3 | K025 | Octane | CH3(CH2)3CH3 |
| K005 | Ethyl formate | HCOOCH2CH3 | K026 | Nonane | CH3(CH2)7CH3 |
| K006 | Ethyl methyl ether | CH3OCH2CH3 | K027 | Carbon monoxide | CO |
| K007 | Ethane | CH3CH3 | K028 | Ammonia | NH3 |
| K008 | Ethyne | CH≡CH | K029 | Hydrogen | H2 |
| K009 | Ethanol | CH3CH2OH | K030 | Benzene | C6H6 |
| K010 | Ethylbenzene | CH3CH2C6H5 | K031 | Iso-butane | (CH3)2CHCH3 |
| K011 | Ethylene | CH2=CH2 | K032 | Isopropanol | (CH3)2CHOH |
| K012 | Methyl acetate | CH3COOCH3 | K033 | 1-Butanol | CH3(CH2)2CH2OH |
| K013 | Ethyl acetate | CH3COOCH2CH3 | K034 | Cyclohexane | CH2(CH2)4CH2 |
| K014 | N-butyl acetate | CH3COOCH2(CH2)2CH3 | K035 | Cyclopentane | CH2(CH2)3CH2 |
| K015 | Propane | CH3CH2CH3 | K036 | Epoxypropane | CH3CHCH2O |
| K016 | Propanol | CH3CH2CH2OH | K037 | Ethylene oxide | CH2CH2O |
| K017 | Propylene | CH2=CHCH3 | K038 | Diethyl ether | (CH3CH5)2O |
| K018 | Acetone | (CH3)2CO | K039 | Dimethyl ether | (CH3)2O |
| K019 | Butane | C4H10 | K040 | Xylene | C6H4(CH3)2 |
| K020 | Butanone | CH3CH2COCH3 | K041 | Gasoline | C4~C12hydrocarbon mixture |
| K021 | Butadiene | CH3CH2COCH3 | K042 | Jet fuel, kerosene | C9~C16hydrocarbon mixture |
