Gantry Crane

Request a Quote Not what you need, please send your RFQs via Email.
Download this page

Details

Gantry Crane

MAIN SPECIFICATIONS

Load tipping moment 100 t*m~1200t*m Classification A5~A8
Lifting capacity 25 t~120t Power supply 380V 50HZ
Max.Radius 40m~80m Max.wheel load <250KN
Lifting Speed 0m/min~30m/min Slewing speed 0.5r/min~2.0r/min
Derricking Speed 15m/min~25m/min Traveling speed 20m/min~30m/min
Luffing modality Rope luffing /Rack luffing
Room system Lattice jib/Box jib ;Double link jib in parallelogram /Single-jib
Load handing device Liffting hook
Electrical control PLC General control or General control & frequency conversion controlor frequency conversion control
Room system Bulk goods/cargo /container
