HY-4 Offshore Personal Transfer Basket

  • Category:Personal Transfer Basket
  • Material:Polyester, Weave rope and steel frame
  • Standards:EN 14502-1:2005
  • Certificate:CE ABS MEDEC 3CF CCS
  • Delivery Time:15-20days
  • Supply Ability:15 sets/month
  • Fob Price:Get Latest Price Now
  • Place of Origin:China
Request a Quote Not what you need, please send your RFQs via Email.

Details

Description:

Our products Platform Lifting Baskets by the Verification Services Group inspection and testing in accordance with APISPEC, 2C offshore crane specification and the International Maritime Organization Convention on the safety of life at sea, we have CE, MEDEC, DNVGL, RINA, BV, ABS, USCG, CCS, 3CF certificate and certificate of patent. We have more than 10 years of experience in related industries, we have domestic and foreign offshore oil and ship supply thousands of sets of corresponding equipment, good customer feedback, the same type of products can be comparable and foreign, the price is only 1/3 in Europe and USA.

Technical Data:

Horizontal
Type
Model Height Chassis diameter Allowable Person Safe working load
(KG)
buoyancy
(person)
Sling material Weight
(KG)
Volume
HY-4 6320 1420 4 380 2 Stainless Steel Wire Rope 70 0.45
HY-6 10050 1600 6 570 3 Stainless Steel Wire Rope 95 0.65
HY-10 10050 1860 10 950 5 Stainless Steel Wire Rope 100 0.8
HY-18 10050 2500 18 1700 9 Stainless Steel Wire Rope 150 1.6
HY-(Ⅱ)-4 6320 1400 4 380 2 High strength polypropylene 80 0.65
HY-(Ⅱ)-6 10050 1600 6 570 3 High strength polypropylene 100 0.85
HY-(Ⅱ)-10 10050 1640 10 950 10 High strength polypropylene 120 1
Vertical
Type
HYL-4 6320 1420 4 380 _ Stainless Steel Wire Rope 250 5.5
HYL-6 6320 1600 6 570 _ Stainless Steel Wire Rope 280 6.5
HYL-10 6320 1640 10 950 _ Stainless Steel Wire Rope 290 7
HYL-12 6320 1800 12 1140 _ Stainless Steel Wire Rope 360 9.2
