Mairne Seawater ice-making machine

Request a Quote Not what you need, please send your RFQs via Email.

Details

China Mairne Seawater ice-making machine:

Introudced advanced European technology, with the feature of Chinese fish boat, develop marine seawater ice-making machine to fit china’s national conditions. Install in limited finish boat space directly , making flake ice through use of water, to keep fresh for seafood product in time.

Feature of marine seawater ice-making machine:

1. Use seawater to make ice , ice block shape is like fish scale. Thickness 1.5-2.2mm, ice-temperature -0.6℃-10℃, has salinity , high valve to keep fish.

2. Use ship’s power directly, adapt to severe sea conditions, making ice normally under 35 degree of ship sway.

3. Full –automatic control system, make ice at any time , no hand operation, safe and reliable , labor-cost saving, low-operation cost.

4. Ice-machine adopt 316 stainless steel, anti-corrosion, main component adopt marine configuration, the service life of the machine is more than ten years.

Type Daily output Compressor Installation power Net Weight External dimension
MFI-10 1200KG 5HP 4kw 430kg 1330*820*1075
MFI-20 2300KG 10HP 7.5kw 680kg 1370*1130*1185
MFI-30 3200KG 15HP 11kw 760kg 1400*1130*1345
MFI-65 6500KG 25HP 19.4kw 1180kg 1680*1250*1580
MFI-75 7500KG 40HP 30.2kw 1800kg 1800*1500*1700
MFI-100 10000KG 50HP 37.6kw 2200kg 2000*1600*1900
MFI-150 15000KG 75HP 55.5kw 3750kg 2500*2500*2400
MFI-200 20000KG 95HP 70kw 4800kg 2500*2500*2800
