Marine Air-conditioner System
- Category:Marine Air Conditioner
- Standards:CCS, BV, ABS, GL，LR, NK
- Packing Details:Standard Export Packaging
- Delivery Time:15-20days
- Supply Ability:15 sets/month
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China Marine Air-conditioner System:
| Model | MPAC- | MPAC- | MPAC- | MPAC- | MPAC- | |
|
Cooling capacity(kw) |
10.46 | 11.6 | 14.4 | 17.44 | 22.6 | |
| Refrigerant | R22(R404) | |||||
| Power supply | AC380V 3PH 50HZ | |||||
| Compressor | Hermtic | |||||
| Condenser | Horizontal shell and tube, aluminum brass tube | |||||
| Evaporator | Copper tube with copper fin | |||||
| Power of low noise centrifugal fan(kw) | 0.16 | 0.16 | 0.55 | 0.55 | 2*0.16 | |
| Protections |
High pressure, low
pressure, oil pressure, water-break, antifreezing, phase loss, overload ,safety valve etc. |
|||||
| Length(mm) | 718 | 810 | 900 | 900 | 1100 | |
| Width(mm) | 490 | 500 | 535 | 535 | 600 | |
| Hight（mm) | 1575 | 1575 | 1575 | 1575 | 1575 | |
| Net weight(kg) | 310 | 320 | 360 | 400 | 480 | |
