Nylon Rope
- Category:Mooring Rope
- Material:nylon/polyester/Polyamide
- Certificate:ABS , BV, DNV , KR, LR , GL , CCS, RINA , mill certificate etc.
- Standards:International standard.
- Fob Price:Get Latest Price Now
- Place of Origin:China
- Attachment:[pdf]Nylon Rope.pdf
Details
China Nylon Rope:
Nylon rope,also know as polyamide rope,it is the well known and has gained the widest acceptance of the synthetic fibre ropes.
The rope has the ability to return to it's original length after being stretched.
Application:
Ideal for use as lifting
rope,towing hawsers, surge lines, mountain climbing ropes, safety lines, boat
falls, drop hammer ropes, mooring rope, fishing ropes and industrial slings.
Some properties of nylon ropes are:
Light weight,excellent elasticity and tensile recovery,superior absorption of impact and shock loads,good flexibility,good sunlight and weather resistance,high melting point.
Good abrasion resistance,resistant to oil and most chemical. good resistance to weathering.
Approval:ABS, DNV,BV, GL,LR, CCS etc.
Parameter Table:
Specification | Polyamide Multifilament | Polyamide Yarn | |||
Diameter | Circumference | Linear Density(Ktex) | Breaking Strength(KN) | Linear Density(Ktex) | Breaking Strength(KN) |
20 | 2 1/2“ | 247 | 79.2 | 247 | 66.7 |
24 | 3“ | 355 | 112 | 355 | 96.3 |
28 | 3 1/2“ | 484 | 149 | 484 | 127 |
32 | 4“ | 632 | 192 | 632 | 161 |
36 | 4 1/2“ | 800 | 240 | 800 | 200 |
40 | 5“ | 987 | 294 | 987 | 241 |
44 | 5 1/2“ | 1190 | 351 | 1190 | 289 |
48 | 6“ | 1420 | 412 | 1420 | 338 |
52 | 6 1/2“ | 1670 | 479 | 1670 | 393 |
56 | 7“ | 1930 | 550 | 1930 | 450 |
60 | 7 1/2“ | 2220 | 627 | 2220 | 513 |
64 | 8“ | 2530 | 709 | 2530 | 579 |
72 | 9“ | 3200 | 887 | 3200 | 723 |
80 | 10“ | 3950 | 1080 | 3950 | 884 |
88 | 11“ | 4780 | 1300 | 4780 | 1053 |
96 | 12“ | 5690 | 1530 | 5690 | 1239 |
104 | 13“ | 6670 | 1780 | 6670 | 1482 |
112 | 14“ | 7740 | 2050 | 7740 | 1690 |
120 | 15“ | 8880 | 2340 | 8880 | 1930 |
128 | 16“ | 10100 | 2650 | 10100 | 2187 |
136 | 17“ | 11400 | 2980 | 11400 | 2461 |
144 | 18“ | 12800 | 3320 | 12800 | 2751 |
160 | 20“ | 15800 | 4060 | 15800 | 3395 |
