R3S Offshore Studless Link Mooring Chain
- Category:Studless Link Mooring Chain
- Material:Rolled Steel Bars
- Certificate:ABS, LR, BV, GL, RINA, DNV, NK, KR, CCS
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China R3S Offshore Studless Link Mooring Chain:
R3S Studless Link Mooring Chain is higher grade than R3 Studless link mooring chain, the chains approved by International Class Society.
Main Specification
Size: 32mm- 162mm
Grade: R3S
Finish: Black Painted.
Testing Report: ABS, LR, BV, GL, RINA, DNV, NK, KR, CCS
Proof Load for R3S Studless Link Mooring Chain
Dia. | Break Load (KN) | Proof Load(KN) | Wight | ||
R3S | API | R3s | API | ||
Studless | Studless | Studless | |||
Mm. | kN | kN | kN | kN | Kgs/m |
19 | 382 | 324 | 267 | 285 | 7 |
20.5 | 443 | 376 | 310 | 249 | 8 |
22 | 509 | 431 | 356 | 286 | 10 |
24 | 604 | 511 | 422 | 339 | 12 |
26 | 706 | 598 | 493 | 397 | 14 |
28 | 815 | 691 | 570 | 458 | 16 |
30 | 932 | 790 | 651 | 524 | 18 |
32 | 1057 | 895 | 738 | 594 | 20 |
34 | 1188 | 1007 | 830 | 668 | 23 |
36 | 1327 | 1124 | 927 | 746 | 26 |
38 | 1473 | 1248 | 1029 | 828 | 29 |
40 | 1625 | 1377 | 1136 | 914 | 32 |
42 | 1785 | 1513 | 1247 | 1004 | 35 |
44 | 1951 | 1654 | 1364 | 1097 | 39 |
46 | 2124 | 1800 | 1485 | 1194 | 42 |
48 | 2304 | 1952 | 1610 | 1295 | 46 |
50 | 2490 | 2110 | 1740 | 1400 | 50 |
52 | 2682 | 2273 | 1874 | 1508 | 54 |
54 | 2881 | 2441 | 2013 | 1620 | 58 |
56 | 3086 | 2615 | 2156 | 1735 | 63 |
58 | 3297 | 2794 | 2304 | 1854 | 67 |
60 | 3514 | 2978 | 2455 | 1976 | 72 |
62 | 3737 | 3166 | 2611 | 2101 | 77 |
64 | 3965 | 3360 | 2771 | 2230 | 82 |
66 | 4200 | 3559 | 2935 | 2361 | 87 |
68 | 4440 | 3762 | 3102 | 2496 | 92 |
70 | 4685 | 3970 | 3274 | 2634 | 98 |
73 | 5064 | 4291 | 3538 | 2847 | 107 |
76 | 5454 | 4621 | 3811 | 3066 | 116 |
78 | 5720 | 4847 | 3997 | 3216 | 122 |
81 | 6130 | 5194 | 4283 | 3446 | 131 |
84 | 6550 | 5550 | 4577 | 3683 | 141 |
87 | 6981 | 5916 | 4878 | 3925 | 151 |
90 | 7422 | 6289 | 5187 | 4173 | 162 |
92 | 7722 | 6544 | 5396 | 4342 | 169 |
95 | 8180 | 6932 | 5716 | 4599 | 181 |
97 | 8490 | 7195 | 5933 | 4774 | 188 |
100 | 8964 | 7596 | 6264 | 5040 | 200 |
102 | 9285 | 7868 | 6488 | 5220 | 208 |
105 | 9773 | 8282 | 6829 | 5495 | 221 |
107 | 10103 | 8561 | 7060 | 5681 | 229 |
111 | 10775 | 9130 | 7529 | 6058 | 246 |
114 | 11287 | 9565 | 7887 | 6346 | 260 |
117 | 11807 | 10005 | 8251 | 6639 | 274 |
120 | 12334 | 10452 | 8619 | 6935 | 288 |
122 | 12690 | 10753 | 8868 | 7135 | 298 |
124 | 13048 | 11057 | 9118 | 7336 | 308 |
127 | 13591 | 11516 | 9497 | 7641 | 323 |
130 | 14139 | 11981 | 9880 | 7950 | 338 |
132 | 14508 | 12294 | 10138 | 8157 | 348 |
137 | 15441 | 13085 | 10790 | 8682 | 375 |
142 | 16388 | 13887 | 11454 | 9214 | 403 |
147 | 17347 | 14700 | 12122 | 9753 | 432 |
152 | 18317 | 15522 | 12800 | 10299 | 462 |
157 | 19297 | 16352 | 13484 | 10850 | 493 |
162 | 20284 | 17188 | 14174 | 11405 | 525 |
165 | 20879 | 17693 | 14590 | 11739 | 545 |
168 | 21477 | 18199 | 15008 | 12075 | 564 |
171 | 22076 | 18707 | 15427 | 12412 | 585 |
175 | 22877 | 19368 | 15986 | 12863 | 613 |
178 | 23479 | 19896 | 16407 | 13201 | 634 |
180 | 23880 | 20236 | 16688 | 13427 | 648 |
185 | 24884 | 21087 | 17389 | 13991 | 685 |
