Rigging Screw Jaw/Swage Stud, SS304 OR SS316
- Category:Turnbuckle
- Material:Stainless steel
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China Rigging Screw Jaw/Swage Stud, SS304 OR SS316:
![](/photos/SWAGE-STUD,-SS304-OR-SS316-1.jpg)
SIZE |
Φ mm |
Φ1 mm |
Φ2 mm |
A mm |
B mm |
C mm |
SWL kgs |
BL kgs |
2.8 | 5 | 5.5 | 2.8 | 155 | 80 | 10 | 150 | 600 |
3.5 | 5 | 6.2 | 3.5 | 155 | 82 | 6.8 | 200 | 800 |
3.3 | 6 | 6.35 | 3.3 | 176 | 92 | 10 | 250 | 1000 |
4.4 | 6 | 7.4 | 4.4 | 174 | 92 | 10.5 | 300 | 1200 |
4.3 | 8 | 7.5 | 4.3 | 190 | 112 | 11 | 350 | 1400 |
5.3 | 10 | 9 | 5.3 | 237 | 120 | 15 | 550 | 2200 |
6.3 | 12 | 12.58 | 6.3 | 288 | 150 | 17 | 1000 | 4000 |
7.3 | 14 | 14.2 | 7.3 | 331 | 170 | 15 | 1350 | 5400 |
8.3 | 16 | 16 | 8.3 | 372 | 190 | 20 | 1625 | 6500 |
10.3 | 20 | 20 | 10.3 | 459 | 220 | 30 | 2125 | 8500 |
