Swageless Jaw Terminal, SS304 OR SS316

Request a Quote Not what you need, please send your RFQs via Email.
Download this page

Details

China Swageless Jaw Terminal, SS304 OR SS316:

SIZE D1
DIAM.WIRE (mm) 		A
mm 		L1
mm 		L2
mm 		L3
mm 		KW
mm 		KW1
mm 		WEIGHT
/ 100 pcs (KG)
Φ3 3 6.25 49 57 8 12 14 4
Φ4 4 7.9 60.5 71.4 8.3 14 19 8
Φ5 5 9.7 69 79 10 16 22 12
Φ6 6 11 81 93 12 19 27 21
Φ8 8 13 106 120 15 24 30 37.6
Φ10 10 16 119 137 13 32 27 --
Φ12 12 19 142 164 15 36 30 --
