Turnbuckle DIN 1480(SS304 OR SS316)

Request a Quote Not what you need, please send your RFQs via Email.
Download this page

Details

China Turnbuckle DIN 1480(SS304 OR SS316):

SIZE LA L2 m b da di i W.L.L
mm mm mm mm mm mm mm mm T
M6 110 60 10 53 10 20 4.5 0.2
M8 110 60 14 55 12 26 6.5 0.4
M10 125 65 20 60 14 30.5 8 0.65
M12 125 75 21 70 18 37.5 10.5 0.9
M16 170 100 27 90 22 48 13 1.8
M20 200 115 34 100 25 51 20 2.75
M24 255 140 39 130 28 66 27 3.99
M30 255 145 45 130 35 83 31 6.25
M32 295 160 55 150 36.5 88 33 6.5
M36 295 160 55 150 44 104 40 9
M38 330 185 63 170 42 104 39 9.5
