VC Series Yatch Capstan Winch

Features

1.Designed for simple, low cost anchor recovery on smaller boats and rope hauling on larger vessels

2.line hauling from any direction

3.High quality finish on above deck components

4.Simplified through deck installation by modular design and precise alignment of gearbox to the top works utilising marine-grade stainless steel bolts

5.Compact, reliable gearbox, made of corrosion resistant material

6.Heavy duty ,dual direction motors, designed for marine winches

7.Easily disassembled for servicing

8.Fit include hand-switch, foot-switch, control box and wrench


Specifications

VC series Specifications






Model Weight Power Motor No load Max. Max. Line Rope Chain

Net(DC) DC (W) absorption load Pull Speed size size
YDVC-001 17KG 12V/24V 600 50A 190kg 680kg 30m/min 12mm 6-7mm
YDVC-002 22KG 12V/24V 1000 100A 350kg 950kg 25m/min 14-16mm 8-10mm
