WP18L Marine Low Pressure Air Compressor
- Category:Low Pressure Air Cooled Marine Air Compressor
- Certificate:CCS
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
Design Particulars:
Max Pressure 0.8/1.0MPa
V-type/W-type arranged, Low vibration
Air-cooled type, avoid costs for water circuit
Lubrication system: splash/pressure oil lubrication
Performance data with 5% tolerance
Standard voltage and frequency: 380V/50HZ, 440V/60HZ.
Tecahnical Data:
| Model |
Pressure (MPa) |
Stages |
Speed/rpm （50Hz） |
Speed/rpm （60Hz） |
Capacity (m3/h) |
Power required (KW) |
Power of motor (KW) |
Cooling air required (L/min） |
Dimension (LxWxH) |
| WP18L | 0.8/1.0 | 1 | 1170 | 20 | 2.1 | 3 | 11 | 884*640*534 | |
| 1 | 1450 | 24 | 2.5 | 3 | 14 | ||||
| 1 | 1750 | 30 | 3.2 | 4 | 18 | ||||
| WP25L | 0.8/1.0 | 1 | 1170 | 38 | 3.6 | 4 | 20 | 884*640*534 | |
| 1 | 1450 | 44 | 4.2 | 5.5 | 24 | ||||
| 1 | 1750 | 55 | 4.2 | 5.5 | 36 | ||||
| WP32L | 0.8/1.0 | 1 | 970 | 38 | 5.4 | 5.5 | 30 | 930*640*534 | |
| 1 | 1170 | 45 | 5.6 | 7.5 | 46 | ||||
| 1 | 1450 | 56 | 6.8 | 7.5 | 56 | ||||
| 1 | 1750 | 68 | 8.2 | 11 | 68 |
Special Pressure 4.0Mpa Model:
| Model |
Discharge Pressure (MPa) |
inlet Pressure (MPa) |
Stages |
Speed/rpm （50Hz） |
Capacity (m3/h) |
Power required (KW) |
Power of motor (KW) |
Cooling air required (L/min） |
Dimension (LxWxH) |
| WP18L | 4 | 0.5 | 1 | 970 | 30 | 5.4 | 5.5 | 30 | 884*640*534 |
