WZW Series Marine Self-Priming Polluted Water General Service Pump
- Category:Centrifugal Pump
- Material:Cast iron pump cast, Bronze impeller, Stainless steel pump shaft
- Standards:standard
- Certificate:CCS
- Fob Price:Get Latest Price Now
- Place of Origin:China
- Attachment:[pdf]Wzw Series Marine Self Priming Polluted Water Pump.pdf
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China WZW Series Marine Self-Priming Polluted Water General Service Pump:
The pump widely applies to delivering polluted water, fibre, solid pareicles, slag, paperpulp and so on.
Structure
The pump is designed with store water room, horizontal bearing box. There’re two kinds of axle-seals, mechanical seal and skeleton seal. There’s an effusion entrance at the top of pump in order to operate conveniently.
Main Specification
Type | Capacity | Head | Self-Priming Height | Speed | Motor Power | Discharge Port | |
m3/h | m | m | m | kw | mm | ||
80WZW | 54 | 13 | 1470 | 5.5 | 80 | ||
100WZW | 100 | 16 | 7 | 1450 | 11 | 100 | |
150WZW | 200 | 22 | 7 | 1450 | 22 | 150 |
