Yatch Vertical Windlass With AC Mode
- Category:Yacht Windlass & Winch
- Material:Stainless steel 304,316, 316L
- Standards:standard
- Packing Details:Standard Packing
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
Yatch Vertical Windlass With AC Mode
AC Vertical windlass (3000W,4000W,5500W,7500W)
Stainless steel vertical windlass.Available in high or low profile, with different drives and for boats up to 50m.The NYS windlass can use chains up to 18mm with stud link in diameter. Possibility of 230V,400V ,12V,24V .
Main parameter
| AC Specification |
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
| Electric motor | 3000W | 4000W | 5500W | 7500W | ||||||
| Motor supply | 12V/24V | 230V/400V | 230V/400V | 230V/400V | ||||||
| Max. lift load | 2500KG | 3100KG | 3500KG | 3600KG | ||||||
| Working load | 1400KG | 1600KG | 1700KG | 1800KG | ||||||
| Line speed | 15m/min | 15m/min | 15m/min | 15m/min | ||||||
| Chain(DIN766) | 12.5mm-13mm | 14mm | 16mm | 18mm | ||||||
