CDSL Marine Electrical Vertical Reciprocating Pump

Request a Quote Not what you need, please send your RFQs via Email.
Download this page

Details

China CDSL Marine Electrical Vertical Reciprocating Pump:

CDSL marine electrical vertical reciprocating pump

General discription

It is suitable to transport sea water,fresh water,petroleum and petroleum product,the temperature of the transported medium divided into three ranks of high,middle and low.(1).H-high temperature pump no more than 220 c with viscosity no more than 5.86x10-4 m3/s(2).M-middle temperature pump no more than 110 c with viscosity no more than 5.86x10-4 m3/s (3).L-low temperature pump no more than 85 c with viscosity no more than 5.86x10-4 m3/s

Performance parameter

(380v/50hz)

Model flow rate pressure Piston range Reciprocating diameter of the outlet motor power
Q(m3/h) (Mpa) (mm) (min-1) (mm) (kw)
2CDSL-15/0.3 15 0.3 132 75 65 3
2CDSL-15/0.4 15 0.4 132 75 65 4
2CDSL-15/0.5 15 0.5 132 75 65 5.5
2CDSL-15/0.6 15 0.6 132 75 65 5.5
2CDSL-15/0.7 15 0.7 132 75 65 5.5
2CDSL-15/0.8 15 0.8 132 75 65 7.5
2CDSL-15/1.0 15 1 132 75 65 11
2CDSL-25/0.3 25 0.3 132 75 65 5.5
2CDSL-25/0.4 25 0.4 132 75 65 5.5
2CDSL-25/0.5 25 0.5 132 75 65 7.5
2CDSL-25/0.6 25 0.6 132 75 65 7.5
2CDSL-25/0.7 25 0.7 132 75 65 11
2CDSL-25/0.8 25 0.8 132 75 65 11
2CDSL-25/1.0 25 1 132 75 65 15
2CDSL-35/0.3 35 0.3 132 148 80 5.5
2CDSL-35/0.4 35 0.4 132 148 80 7.5
2CDSL-35/0.5 35 0.5 132 148 80 11
2CDSL-35/0.6 35 0.6 132 148 80 11
