M type Rubber Fender
- Category:Marine Fender
- Material:Natural Rubber
- Packing Details:Export standard packaging.
- Delivery Time:10 to 15 days.
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China M type Rubber Fender:
High energy absorption,low reaction force.
The installation is firm, easy to change.
Specification:
Size:
| Model | h(mm) | s(mm) | w(mm) | b(mm) | C(mm) | d(mm) |
| M300H | 300 | 396 | 60 | 204 | 140 | 750 |
| M400H | 400 | 528 | 80 | 272 | 150 | 1000 |
| M500H | 500 | 660 | 100 | 340 | 160 | 1250 |
| M600H | 600 | 776 | 120 | 408 | 170 | 1500 |
| M800H | 800 | 1035 | 160 | 544 | 180 | 2000 |
Performance List:
| Specification | Compression Deformation 50% | |||||
| High Reaction Force | Standard Reaction Force | Low Reaction Force | ||||
| Force(KN) | Absorption(KN-M) | Force(KN) | Absorption(KN-M) | Force(KN) | Absorption(KN-M) | |
| M300 | 257 | 29.4 | 213 | 24.3 | 182 | 20.6 |
| M400 | 341 | 53 | 282 | 44.1 | 242 | 37.2 |
| M500 | 427 | 83.3 | 354 | 68.6 | 304 | 58.8 |
| M600 | 514 | 120 | 425 | 100 | 366 | 84.2 |
| M800 | 685 | 213 | 566 | 177.3 | 486 | 150 |
