US Type Swivel G-401
- Category:Chain Swivel
- Material:Stainless steel
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China US Type Swivel G-401:
| SIZE |
A inch |
B inch |
C inch |
D inch |
E inch |
G inch |
J inch |
M inch |
R inch |
T inch |
U inch |
V inch |
WLL T |
| 1/4 | 1.25 | •69 | .75 | •62 | 1.12 | .25 | •69 | .31 | 2.25 | 2.75 | 1.69 | 1.25 | 850 |
| 5/6 | 1.63 | •81 | 1.00 | .75 | 1.38 | .31 | .81 | •38 | 2.72 | 3.34 | 2.06 | 1.47 | 1250 |
| 3/8 | 2.00 | .94 | 1.25 | 1.00 | 1.75 | .38 | 1.00 | .50 | 3.44 | 4.19 | 2.5 | 1.88 | 2500 |
| 1/2 | 2.50 | 1.31 | 1.50 | 1.25 | 2.25 | •50 | 1.31 | •63 | 4.25 | 5.25 | 3.19 | 2.44 | 3600 |
| 5/8 | 3.00 | 1.56 | 1.75 | 1.50 | 2.75 | •62 | 1.50 | •75 | 5.13 | 6.31 | 3.88 | 2.94 | 5200 |
| 3/4 | 3.50 | 1.75 | 2.00 | 1.75 | 3.25 | •75 | 1.88 | .88 | 5.78 | 7.22 | 4.94 | 3.46 | 7200 |
