Polypropylene Rope
- Category:Mooring Rope
- Material:Polypropylene,PP
- Certificate:ABS, DNV, LR, GL, KR, BV, CCS, RINA, etc
- Standards:International standard.
- Fob Price:Get Latest Price Now
- Place of Origin:China
- Attachment:[pdf]Polypropylene Rope.pdf
Details
China Polypropylene Rope:
Construction:3 strand,4 strand,6 strand,8 strand,12 strand,16 strand rope,etc.
Type:twisted,braided.
Diameter:4mm to 150mm.
Color: white,yellow,black and others as requested.
Usage: marine ship, oil tanker, warships, tugs, oil fields, mines, port and other areas etc.
It is the most popular type rope,suitable for a various use,multi-functional. It is not tough,but it have a high strength even it is wet,and itis immune to attack by rot and mildew and is highly resistant to attack by acids and alkalis.It is also an excellent non-conductor of electricity.
3 Strand Polypropylene Rope Parameter Table:
| Specification | Polypropylene MultiFilament | Polypropylene | Polyester/Polypropylene mixed | ||||
| Diameter | Circumference | Linear Density(Ktex) | Breaking Strength(KN) | Linear Density(Ktex) | Breaking Strength(KN) | Linear Density(Ktex) | Breaking Strength(KN) |
| 20 | 2 1/2“ | 189 | 62.6 | 180 | 56.9 | 194 | 68.7 |
| 24 | 3“ | 273 | 87.7 | 260 | 79.7 | 279 | 96.3 |
| 28 | 3 1/2“ | 373 | 115 | 355 | 105 | 380 | 130 |
| 32 | 4“ | 483 | 146 | 460 | 132 | 497 | 167 |
| 36 | 4 1/2“ | 614 | 182 | 585 | 166 | 629 | 210 |
| 40 | 5“ | 756 | 221 | 720 | 201 | 776 | 257 |
| 44 | 5 1/2“ | 924 | 266 | 880 | 242 | 939 | 308 |
| 48 | 6“ | 1092 | 308 | 1040 | 280 | 1110 | 364 |
| 52 | 6 1/2“ | 1281 | 357 | 1220 | 325 | 1320 | 424 |
| 56 | 7“ | 1491 | 408 | 1420 | 371 | 1520 | 489 |
| 60 | 7 1/2“ | 1712 | 467 | 1630 | 424 | 1750 | 558 |
| 64 | 8“ | 1943 | 528 | 1850 | 480 | 1990 | 631 |
| 72 | 9“ | 2457 | 663 | 2340 | 603 | 2520 | 789 |
| 80 | 10“ | 3045 | 815 | 2900 | 741 | 3110 | 963 |
| 88 | 11“ | 3686 | 978 | 3510 | 890 | 3750 | 1160 |
| 96 | 12“ | 4379 | 1155 | 4170 | 1050 | 4470 | 1370 |
| 104 | 13“ | 5145 | 1325 | 4900 | 1204 | 5260 | 1590 |
| 112 | 14“ | 5985 | 1529 | 5700 | 1390 | 6050 | 1840 |
| 120 | 15“ | 6825 | 1756 | 6500 | 1596 | 6980 | 21400 |
| 128 | 16“ | 7770 | 1982 | 7400 | 1802 | 7950 | 2370 |
| 136 | 17“ | 8820 | 2231 | 8400 | 2029 | 8950 | 2660 |
| 144 | 18“ | 9870 | 2490 | 9400 | 2264 | 10100 | 2970 |
| 160 | 20“ | 12100 | 3051 | 11521 | 2774 | 12500 | 3630 |
Feature:
Light weight,high tenacity,great appearance, High resistant to rot, mildew, moisture and chemicals property with beautiful appearance.Easy operation, low enlongation, high strength, soft
