VHF 1500
- Category:Marine Communication And Navigation Equipment
- Standards:standard
- Certificate:CCS
- Packing Details:Standard Packing
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
VHF 1500
(1).Main function
1.Dual-Watch and Tri-Watch
2.All US, International and Canadian , 10 Weather Channel
3.One button change Channel 16 and Channel 9
4.Except 88 dedicated channels , user-program 100 channels
5.Priority scan
2.All US, International and Canadian , 10 Weather Channel
3.One button change Channel 16 and Channel 9
4.Except 88 dedicated channels , user-program 100 channels
5.Priority scan
(2).Overall Specifications
1.Frequency Range : Tx: 156.025Mhz-157.425Mhz
Rx: 156.050Mhz-163.275Mhz
2.All US, International and Canadian , 10 Weather Channel
3.number of channels：88
4.Channel spacing：25KHz
5.Modulation method：FM（16K0J3E）
6.Operating temperature range: –20°C to +60°C
7.Power Supply :DC 13.8V
8.Dimensions：152（W）×67（H）×144（D）mm
9.Weight：0.9Kg
Rx: 156.050Mhz-163.275Mhz
2.All US, International and Canadian , 10 Weather Channel
3.number of channels：88
4.Channel spacing：25KHz
5.Modulation method：FM（16K0J3E）
6.Operating temperature range: –20°C to +60°C
7.Power Supply :DC 13.8V
8.Dimensions：152（W）×67（H）×144（D）mm
9.Weight：0.9Kg
(3).Transmitter Specifications
1.Output power： 25W / 1W
2.Frequency tolerance：≤ ±10ppm
3.Modulation limit：≤ ±5KHz
4.Spurious emissions：≤ - 65dB
5.Tx Current consumption：High ≤ 6.0A , Low ≤ 1.5A（DC13.8V）
6.Audio distortion：≤ 7%
2.Frequency tolerance：≤ ±10ppm
3.Modulation limit：≤ ±5KHz
4.Spurious emissions：≤ - 65dB
5.Tx Current consumption：High ≤ 6.0A , Low ≤ 1.5A（DC13.8V）
6.Audio distortion：≤ 7%
(4).Receiver Specifications
1.Reference sensitivity：≤ 0.2μV（12dB）
2.Squelch sensitivity：≤ 0.15μV
3.Modulation receiver bandwidth：≥ 2×5KHz
4.Adjacent Channel Selectivity：≥ 65dB
5.Intermodulation rejection ratio：≥ 58dB
6.Spurious response：≥ 65dB
7.Audio output power：≥ 2.5W（8Ω）
8.Audio distortion：≤ 7%
Note: Specifications are subject to change without notice.
2.Squelch sensitivity：≤ 0.15μV
3.Modulation receiver bandwidth：≥ 2×5KHz
4.Adjacent Channel Selectivity：≥ 65dB
5.Intermodulation rejection ratio：≥ 58dB
6.Spurious response：≥ 65dB
7.Audio output power：≥ 2.5W（8Ω）
8.Audio distortion：≤ 7%
Note: Specifications are subject to change without notice.
