OMK-08 Type Oil Water Interface Detector
- Category:Sensor
- Certificate:CCS,GL,LR,BV,ABS,DNV GL,RINA,NK,KR ETC.
- Delivery Time:About 7 to 10 days
- Packing Details:Carton packaging.
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
Product Description:
This equipment is consists of sensor and amplifier,its physical principle is ,when ultrasonic get through the different liquid or interface, the energy will met attenuation or refraction,in this way,to get the oil and water interface detected.
Features:
No moving parts.
No fixed forms.
The installation is very convenient.
Its performance is stable and reliable.
Main Technical Specification:
| Model No. | OMK-08A | OMK-08B |
| Voltage |
AC110V/220V AC220/240V |
DC24V |
| Power consumption | 6VA | |
| Relay output | DPDT | |
| Contact capacity | AC230V 5A | |
| Size | 200x120x75 | |
| Shell | Polycarbonate IP65 | |
| Installation size | 188x88 | |
