Type F Ceiling Panel
- Category:Ceiling Panel
- Material:Rock Wool
- Certificate:ABS, LR, BV, GL, DNV, CCS
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China Type F Ceiling Panel:
Type F Ceiling Panel
Model | Thickness | Fire class | Core material |
T25F | 25mm | B-0 | rock wool |
T50F | 50mm | B-15 | rock wool |
Main Specification
Type | T25F | T50F | |
Fire class | B-0 | B-15 | |
Weight | 6.8kg/m2 | 8.8kg/m2 | |
Sound reduction | -- | -- | |
Thermal transmittance | 1.36Kcal/m2h°C | 0.89Kcal/m2h°C | |
Core material | Rock wool 80kg/m3 | ||
Surface finish | PVC film(150μ,low flame spread) or galvanized steel | ||
Dimension | 25/50mm( t )×600mm( w )×600mm(l) | ||
Tolerances | Thickness0-1×Width0-1×Length±3 |
